Replaces Part Number : For Curtis 1268 / 1268-5403 Made According to Original Products, Quality is Guaranteed, 100% Tested Before Shipping.
Please Refer to Your Own Part and Make Sure Your Part is 48V / 400A / 0-5K??
Applicable Models : Replaces CURTIS 1268-5403 controllers are separately excited motor speed controllers designed for use in a variety of transport vehicles. These programmable controllers are simple to install, efficient, and cost effective. Typical applications include heavy-duty golf carts, personnel transports, burden carriers, and other utility vehicles.
Various throttles can be used with the 1268-5403 controller, including 5k?? 3-wire potentiometers and 0-5V throttles. But 1268-5403 does not support ITS (Inductive Throttle Sensor) type throttle.
1 Year Warranty : We Test Each Item and 100% Ensure That Before We Ship, Before and After Sales, We Will Provide Warranty Service For Damaged Products, True Worry-Free Shopping Experience.
We supply motor controller & assemblage, programmer, contactor, accelerator (throttle), meter / gauge, and many other parts, we provide a wild range of products, corresponding each sector of electric vehicle & forklift.
Motor Controller,For Curtis 1204-027
For Curtis 1204-410/412
For Curtis 1205-5603
For Curtis 1510-5201/5250
For Curtis 1243-4320
For EZ-GO 73326G02
Voltage (Volts)
36V
48V
48V
48v
36V
36V
Current (amps)
275A
325A
500A
275A
300A
350A
Throttle Type
0-5K??
5K-0??
0-5K??0-5V
Battery Voltage:48V(default setting), 36V
Throttle Type: 0-5K??(default setting), 5-0K?? or 0-5V
Current Rating (amps): 400A
If You Need to Modify Any Controller Parameter, You Need to Have a CURTIS 1313-4331 Handheld Programmer.
If Your Motor Controller is Not 48V/ 0-5K??/400A
If You Don’t Sure The Item Compatible With Your Car,
Please Provide The Picture of Your Original Part To Us.
Key Features: For CURTIS Model 1268-5403
Norminal Battery Voltage (Volts): 48V (default setting) or 36VAmature 2 minute current rating (amps): 400Field 2 minute current rating (amps): 50Logic enable and logic power input voltage (minimum): 16.8 VLogic enable and logic power input current (no contactors engaged): 160 mA without programmer; 200 mA with programmerLogic input voltage: 20.0 V High; 7.5 V LowLogic input current 10 mAThrottle Type: various throttles can be used with the 1268 controller, including 5k?? 3-wire
potentiometers and 0?C5V throttles.Net Weight: 3.9 kg
