Features:
Works with 36V Lead-Acid Batteries in Golf Carts, Forklifts, Trucks, RV’s, ATV’s, UTV’s, Scooters, Boats and More
Material: ABS
Waterproof, IP65
Temperature Range: -40F to 185F
Connection: Pin+ Battery+ Pin- Battery- C-single output for external use
1 Year Warranty
Operation
Only when the battery is properly charged then the 10th LED (far right) will be lighted.
As battery??s state of charge decreases, successive LED lights up, only one at a time.
When 2nd (from left) LED flashes, indicating “energy reserve”. When both 1st and 2nd LED flash, indicating “empty”, new battery is needed to replace old one.
Battery indicator memorized the battery state is full when leaving factory. When use with a new battery, it should be powered on for at least 2 minutes to indicate the real battery state.
Range indication: Green: 41~100%, Yellow: 21~40%, Red: 20% less.
Forklift trucks, Golf Carts, RV’s, Boats, Scooters and electric vehicle. etc.
Dimensions: Cut-off: 1.5″x1″, distance between holes: 1.75″, depth: 1.5″
Case Style: Front Panel Mount
Package Contents
(1) 36V LED Battery Indicator Gauge
Hardware Shown
Instructions
