remote car battery disconnect switch system -DC12V, 500A max
Remote Control – Turn on the battery before you start the engine (160 feet remote distance)
remote control electromagnetic battery switch allows you to move the trigger from under the hood to your hand
Do not turn off the battery when your engine is working
This remote battery switch is only for battery on and off, it can’t start your engine
DC12V Remote Control Car Battery Switch 500A model
Why do we need this device 1.Sometime we park our car in one sport for long times (15 days or more),Car battery run off day by day. What if it goes out of battery one day You wont be able to start the car! This device can cut the power off , You just need to turn on the battery with your remote whenever you want to use the car.2. A thief can’t start your car without remote.Notice :1.This device is for battery on / off only , it can’t start your engine;2.Do not turn the power off when your engine is working;3.The remote has been paired properly with the switch .No need to pair them again.Specification:- Upgrade:Silver Contact ; Rated Current: 500A ; Switch Standby Current: 0.005A- Rated Voltage: DC 12V; Working Voltage: DC 11-15V ;- Lifetime of Use: 50,000 Times- Electromagnetic Valve size: 7.8cm (L)*8cm (W)*8.5cm (H)- Working Mode: Remote ControlNotice: Please check the car hood space and voltage of the car batery(12V only) before purchase .
Wire Diagram
About Installation:1. The thin red wire is connected to the “+” port of the battery, and the thin black wire is connected to the “-” port of the battery. Switch can work with power then;2. Two large terminals on the electromagnetic Valve are the main switch, one in ,the other out .(They control “-” or “+” port of the battery actually);3. If you want to control the “-” port, one large terminal is connected to the “-” port of the battery, the other large terminal is connected to the “-” port of the car ground wire. Normally we control the “-” port of the battery;4. To prevent battery short circuit during installation, Pls ask the professional car shop for help if you don’t know how to do it.
With 2 pcs remote transmitters
